Overhead Electric Pole

Overhead electric poles are supporting structures for assembling electric wires. They are mainly made of steel and are galvanized to improve their corrosion resistance and service life.
Place of Origin:Jiangsu, China
Material:Steel, Metal
Height:8m 9m 10m
MOQ:1 Set

Send Inquiry

Description

Technical Parameters

Products Description

Electric Pole

Overhead electric poles serve as support structures for the installation of electrical wires. Typically constructed from steel, these poles undergo galvanization to enhance their resistance to corrosion and extend their lifespan. The galvanization process commonly involves hot-dip galvanizing, which coats the steel with a layer of zinc, creating a protective barrier that safeguards against oxidation and corrosion.

Technical Data

Product Name	Overhead Electric Pole
Material	Commonly Q345B/A572, Q235B/A36, Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, ST52
Height	8M	9M	10M
Dimensions(d/D)	80mm/180mm	80mm/190mm	85mm/200mm
Thickness	3.5mm	3.75mm	4.0mm
Flange	320mm*18mm	350mm*18mm	400mm*20mm
Tolerance of dimension	±2/%
Minimum yield strength	285Mpa
Max ultimate tensile strength	415Mpa
Anti-corrosion performance	Class II
Against earthquake grade	10
Color	Customized
Surface treatment	Hot-dip Galvanized and Electrostatic Spraying, Rust Proof, Anti-corrosion performance Class II
Stiffener	With a big size to strengthen the pole to resist the wind
Wind Resistance	According to local weather conditions, the General design strength of wind resistance is ≥150KM/H
Welding Standard	No crack, no leakage welding, no bite edge, weld smooth level off without the concavo-convex fluctuation or any welding defects.
Hot-Dip Galvanized	Thickness of hot-galvanized is 60-100um. Hot Dip Inside and outside surface anti-corrosion treatment by hot dipping acid. which is in accord with BS EN ISO1461 or GB/T13912-92 standard. The designed life of the pole is more than 25 years, and the galvanized surface is smooth and with the same color. Flake peeling hasn't been seen after the maul test.
Anchor bolts	Optional
Material	Aluminium,SS304 is available
Passivation	Available
