Hot Dip Galvanized Pole

Place of Origin:Jiangsu, China
Material:Steel, Metal
Type:Single Arm
Shape:Round, Octagonal, Dodecagonal or Customized
Application:Street light, Garden light, Highway light or Etc.
MOQ:1 Set
Send Inquiry

Description

Technical Parameters



Products Description



Hot-Dip Galvanized Steel Light Pole has become an indispensable and important component of urban lighting facilities due to its strong corrosion resistance, high durability, beautiful appearance, and high-quality material selection.



Products data



Product Name Hot Dip Galvanized Pole
Material Commonly Q345B/A572, Q235B/A36, Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, ST52
Height 5M 6M 7M 8M 9M 10M 12M
Dimensions(d/D) 60mm/150mm 70mm/150mm 70mm/170mm 80mm/180mm 80mm/190mm 85mm/200mm 90mm/210mm
Thickness 3.0mm 3.0mm 3.0mm 3.5mm 3.75mm 4.0mm 4.5mm
Flange 260mm*14mm 280mm*16mm 300mm*16mm 320mm*18mm 350mm*18mm 400mm*20mm 450mm*20mm
Tolerance of dimension ±2/%
Minimum yield strength 285Mpa
Max ultimate tensile strength 415Mpa
Anti-corrosion performance Class II
Against earthquake grade 10
Color Customized
Surface treatment Hot-dip Galvanized and Electrostatic Spraying, Rust Proof, Anti-corrosion performance Class II
Shape Type Conical pole, Octagonal pole,Square pole, Diameter pole
Arm Type Customized: single arm,double arms,triple arms,four arms
Stiffener With big size to strength the pole to resist the wind
Powder coating Thickness of powder coating is 60 -100um. Pure polyester plastic powder coating is stable and with strong adhesion & strong ultraviolet ray resistance. The surface is not peeling even with blade scratch (15×6 mm square).
Wind Resistance According to local weather condition, General design strength of wind resistance is ≥150KM/H
Welding Standard No crack, no leakage welding, no bite edge, weld smooth level off without the concavo-convex fluctuation or any welding defects.
Hot-Dip Galvanized Thickness of hot-galvanized is 60 -100um. Hot Dip Inside and outside surface anti-corrosion treatment by hot dipping acid. which is in accord with BS EN ISO1461 or GB/T13912-92 standard. Designed life of pole is more than 25 years, and the galvanized surface is smooth and with the same color. Flake peeling hasn't been seen after maul test.
Anchor bolts Optional
Material Aluminium,SS304 is available
Passivation Available



Products advantages



1. Corrosion Resistance:

The zinc coating provides excellent protection against rust and corrosion, significantly extending the lifespan of the pole, especially in harsh environments.
2. Durability:

Hot dip galvanized poles are highly durable and can withstand extreme weather conditions, including heavy rain, snow, and high winds.
3. Low Maintenance:

Due to their corrosion resistance, these poles require minimal maintenance over their lifespan, reducing long-term costs and labor.
4. Cost-Effectiveness:

Although the initial cost may be higher than non-galvanized options, the long-term savings from reduced maintenance and replacement costs make hot dip galvanized poles a cost-effective choice.
5. Environmental Resistance:

The zinc coating protects the underlying metal from environmental factors, including moisture, chemicals, and pollutants, making them suitable for various applications.
6. Versatility:

These poles can be used in a wide range of applications, including lighting, signage, and telecommunications, making them a versatile choice for various industries.
7. Sustainability:

Zinc is a recyclable material, and the galvanization process can be environmentally friendly, contributing to sustainable construction practices.
8. Adhesion and Bonding:

The hot dip galvanization process creates a strong bond between the zinc and the steel, ensuring that the coating adheres well and provides long-lasting protection.
9. Increased Load-Bearing Capacity:

The structural integrity of hot dip galvanized poles can be enhanced, allowing them to support heavier loads compared to non-galvanized alternatives.
10. Safety:

The corrosion resistance of galvanized poles reduces the risk of structural failure over time, contributing to the safety of installations.



Manufacturing Process



light pole manufacturing process



Production inspection



Production testing



Products Applications



1. Utility Poles:

Used for electrical distribution and transmission lines, these poles support power lines and help in the delivery of electricity to homes and businesses.

2. Street Lighting:

Hot dip galvanized poles are commonly used for streetlights, providing illumination for roadways, parking lots, and public spaces.

3. Traffic Signals and Signage:

These poles are used to support traffic lights, road signs, and informational signage, ensuring visibility and safety on roadways.

4. Telecommunication Towers:

Hot dip galvanized poles are utilized in the construction of communication towers for cellular networks, radio, and television broadcasting.

5. Fencing and Guardrails:

They are often used in the construction of fencing systems and guardrails for highways, parks, and other public areas.

6. Flagpoles:

Hot dip galvanized poles are a popular choice for flagpoles due to their strength and resistance to weathering.

7. Sports Lighting:

These poles are used to support lighting systems in sports facilities, stadiums, and recreational areas, ensuring adequate illumination for events.

8. Solar Panel Mounting:

Hot dip galvanized poles can be used to support solar panel arrays, providing a stable and durable foundation for renewable energy systems.

9. Wind Turbine Towers:

In some cases, hot dip galvanized poles are used in the construction of wind turbine towers, providing structural support for renewable energy generation.

10. Marine Applications:

They are suitable for use in coastal and marine environments, where resistance to saltwater corrosion is essential.

11. Industrial Applications:

Hot dip galvanized poles are used in various industrial settings for supporting equipment, lighting, and safety barriers.

12. Public Infrastructure:

These poles are often used in parks, plazas, and other public spaces for lighting, signage, and decorative purposes.
