Some Information About Electric Lifting High Mast Lights

The electric lifting high mast light you searched for is Phoebus's flagship product. We offer a full range of electric lifting high mast lights, including 20-meter, 25-meter, 30-meter, and 35-meter models. As a Jiangsu-based manufacturer of electric lifting high mast lights, we possess complete production equipment and qualifications. Our electric lifting high mast lights are reasonably priced, ensuring a truly win-win partnership!

Electric lifting high mast lights are widely used due to their exquisite appearance, large lighting area, fully automatic lifting, and diverse lighting controls. Phoebus, a high mast pole manufacturer, offers a full range of high mast lights, including solar-powered, liftable, and AC-powered models.

Material control for high mast poles: Given the exposed conditions of high mast lights, all steel components, including the pole, are galvanized for 30 years of corrosion resistance. Steel components utilize plug-in or internal flange connections, eliminating welding hazards on-site. Anodization is applied to aluminum profiles. All exposed standard parts are composed of stainless steel, along with aluminum and stainless steel components. Suspension cables are made of stainless steel and adhere to the most recent national installation standards; electrical components are composed of brass or electrolytic copper that has been silver-plated. A passivation treatment is applied and hot-dip galvanizing is done at least 80 µm.

Lighting fixtures: Simple heat dissipation, efficient temperature control, and long lifespan thanks to aluminum die-cast housing. Internal wiring is resistant to flames and high temperatures, and tempered glass offers thermal stability and filtering. Wiring has a sealed inlet to prevent moisture ingress effectively. The fixture's protection rating is IP65 or higher, and the fixture can withstand wind speeds of 30m/s.

High mast pole light source: Long-life, high-efficiency high-pressure sodium lamps or high-brightness LED light sources with instantaneous triggering function, ranging from 200W to 1000W. Power supply voltage: 220V.

Power factor: Equipped with a sufficient capacity power factor-adjusting capacitor to achieve a power factor of 0.85-0.95. An electrical assembly, a hoisting system, a light pole, and a light panel-which houses the light fixtures-are the parts of an electric lifting high mast light.

1. For convenient upkeep and inspection, the light panel can be raised and lowered. The light fixtures, light source, ballast, trigger, hook assembly, and terminals are all housed in this premium steel plate structure.

2. The light pole is a single, molded, multifaceted pyramidal pole that is usually divided into three to four sections, each measuring seven to ten meters in length. The pole is made of high-quality steel plate, rolled and pressed, with hot-dip galvanized inner and outer surfaces, followed by powder coating. Stainless steel fastening screws are used for safety and aesthetics.

The top of the pole features a pulley system, a limit switch, a hook assembly, a rain cover, and a lightning rod integrated into the pole. An electrical door is located at the bottom of the pole, housing the hoisting system and electrical assembly. A door frame is welded to the edge of the electrical door to compensate for the decrease in strength when the light fixture is open. The electrical door cover has a waterproof protective ring to prevent rainwater penetration.

Welcome to purchase Phoebus electric lifting high mast lights. We offer a full range of specifications, featuring stable and safe electric lifting mechanisms, and maintenance requires no high-altitude work. Direct from the manufacturer, we guarantee reliable quality and affordable prices. Customization is also supported. Inquire now to purchase!
